LM1200 wan connection not working
I want to use LM1200 as a failover device in the North Sierras where when we lose power, the broadband goes out in 20 mins. I have the latest firmware and if I connect only LTE modem it works fine. F...
Thank you John.
I switched to Router mode and I was able get the traffic through. That caused me another problem since the port numbers using public IP was not translated to local IP.
I switched to Bridge mode again and modem stayed connected and everything works great.
Thanks for all the help, now I need to find external antennas to improve the LTE reception.
I have run the firmware update, and both ports appear to be live. I want the device's cellular as a failover only. I have connected from arris modem to nighthawk rax80 router. What is the best setting for successful failover? Bridge, Ping frequency, and router setting recommendations? Etc.
exxchef wrote:
I have run the firmware update, and both ports appear to be live. I want the device's cellular as a failover only. I have connected from arris modem to nighthawk rax80 router. What is the best setting for successful failover? Bridge, Ping frequency, and router setting recommendations? Etc.
Depending on your purpose, if you plans to use LM1200's failover as backup for all your network, it is better to set up LM1200 the following way.
Arris Modem -> LM1200 WAN Port - LM1200 LAN Port -> RAX80.
When Arris fails, LM1200 can switch to 4G network to make sure RAX80 can have data connections.
Thanks
John
thanks John. Bridge?
Yes. Bridge mode is fine.
Thanks
John
With this setup, it's only running cellular and won't pass through the cable modem. says that the landline ethernet is not
I can't seem to get the lm1200 to work as a pass-through with the wireline. Im sure it's something simple, but I don't know what it is!
