calaba
Apr 07, 2016Guide
How can I update SoftEther VPN App to Newest Version - ReadyNAS 10400
Hello all - if anyone is interested in knowing the solution mentioned in this topic here then here is it. Unfortunatelly the topic is already closedso cannot add solution directly there.
Tested on NETGEAR ReadyNAS 10400.
Current version of the VPN App is 1.5 which contains SoftEther VPN Server version 4.12.
I successfully updated the SoftEther VPN Server to latest version as of today 4.19 - Build 9605.
The solution is to download latest binary build for ARM (my ReadyNAS is ARM v7) and then copy it to the folder /apps/vpnserver/bin/arm/ . In this location there is a compilation script which can rebuild the vpnserver and vpncmd executables (ELF) using the latest binary release of the downloaded SoftEther VPN Server.
Steps - ssh root access is required:
1) Stop the VPN Server App in ReadyNAS Web UI
2) ssh to the ReadyNAS box (i.e. using PuTTy)
3) Become root by executing "sudo su" if your user is sudoer or logon directly as user root
4) Install build tools to be able to execute the SoftEther build:
- apt-get update
- apt-get install make libc6-dev gcc gdb libtag1-dev uuid-dev
5) download latest ARM EABI Binary release of the SoftEther VPN Server - in my case 4.19-Build 9605
6) Untar the archive
- tar xvf softether-vpnserver-v4.19-9605-beta-2016.03.06-linux-arm_eabi-32bit.tar.gz
The directory vpnserver is created.
7) Copy the content of the vpnserver directory (the archive extract) over the files in the directory /apps/vpnserver/bin/arm/
8) cd to /apps/vpnserver/bin/arm/ and build the new ELF executables:
- cd /apps/vpnserver/bin/arm/
- ./.install.sh - you have to view & accept the license agreement, after that the new executables (vpnserver and vpncmd) should be build using the files extracted from the latest binary release of the SoftEther VPN Server
9) Now copy everything from /apps/vpnserver/bin/arm/ also one level up to /apps/vpnserver/bin (dunno why it's duplicated there)
10) make sure you return the ownership of the files to the admin user:
- cd /apps/vpnserver
- chown -R admin:admin bin/
11) Cleanup the extracted vpnserver directory and the downloaded archive
12) Start the VPN Server App from ReadyNAS Web UI and Enjoy new version (don't forget to use compatible VPN Client tools)
Maybe someone can write fully automated script ... including the download from the SoftEther VPN Server location ;-)
21 Replies
Sort By
- JennCNETGEAR Employee Retired
Hello calaba,
Thank you for sharing your resolution and/or workaround. We appreciate your contribution to the community.Feel free to post any suggestions, questions, recommendations or anything about your NAS that you think needs attention or will help others.Welcome to the community!Regards,Thanks for you post. I was able to successfully upgrade the RN516. I wanted to shared these instructions, because it will simply future upgrades, because in the future you will need to change the file name and remove the apt-get install steps.
apt-get update
apt-get upgrade
apt-get install build-essential
apt-get install make libc6-dev gcc gdb libtag1-dev uuid-dev
mkdir /root/softether
cd /root/softether
wget http://www.softether-download.com/files/softether/v4.19-9605-beta-2016.03.06-tree/Linux/SoftEther_VPN_Server/64bit_-_Intel_x64_or_AMD64/softether-vpnserver-v4.19-9605-beta-2016.03.06-linux-x64-64bit.tar.gz
tar xvf softether-vpnserver-v4.19-9605-beta-2016.03.06-linux-x64-64bit.tar.gz
cp -avr /apps/vpnserver/bin/vpn_server.config /root/softether/vpnserver/
cp -avr /apps/vpnserver/bin/vpn_server.config.save /root/softether/vpnserver/
make
1
1
1
cp -avr /root/softether/vpnserver/* /apps/vpnserver/bin/arm
cp -avr /apps/vpnserver/bin/arm/* /apps/vpnserver/bin
cd /apps/vpnserver/bin/arm
./vpncmd
3
check
exit
cd /apps/vpnserver
chown -R admin:admin bin/
rm -rf /root/softether- hoogendsAspirant
- JJS68Tutor
Thank you, this worked for me (ReadyNAS 314)
did have to add the below before the make command, but this made it very easy to upgrade, thanks
cd /root/softether/vpnserver
- LaureijsAspirant
I used the combined info above on a ReadyNAS 516:
apt-get update
apt-get upgrade(don't do this, it is not recommended by Netgear and can do damage).
apt-get install build-essential
apt-get install make libc6-dev gcc gdb libtag1-dev uuid-dev
mkdir /root/softether
cd /root/softethertar xvf softether-vpnserver-v4.25-9656-rtm-2018.01.15-linux-x64-64bit.tar.gz
cp -avr /apps/vpnserver/bin/vpn_server.config /root/softether/vpnserver/
cp -avr /apps/vpnserver/bin/vpn_server.config.save /root/softether/vpnserver/
cd /root/softether/vpnservermake
1
1
1
cp -avr /root/softether/vpnserver/* /apps/vpnserver/bin/arm
cp -avr /apps/vpnserver/bin/arm/* /apps/vpnserver/bin
cd /apps/vpnserver/bin/arm
./vpncmd
3
check
exit
cd /apps/vpnserver
chown -R admin:admin bin/
rm -rf /root/softetherjust to confirm.
Laureijs wrote:
apt-get upgrade
This particular step is not recommended, and can create issues with the ReadyNAS application.
So I suggest skipping that one.
Hi i try to use this Tutorial on my ReadyNas 212. But it not works.
i can not run the command "make"
here ist what i have:
root@Mando-NAS:~# root@Mando-NAS:~# apt-get install build-essential
-bash: root@Mando-NAS:~#: command not found
Building dependency tree
Reading state information... Done
Some packages could not be installed. This may mean that you have
requested an impossible situation or if you are using the unstable
distribution that some required packages have not yet been created
or been moved out of Incoming.
The following information may help to resolve the situation:The following packages have unmet dependencies:
build-essential : Depends: gcc (>= 4:10.2) but it is not going to be installed
Depends: g++ (>= 4:10.2) but it is not going to be installed
Depends: dpkg-dev (>= 1.17.11) but it is not going to be installed
E: Unable to correct problems, you have held broken packages.is there any way to add new source to sourcelist to get the archive package for build essential?
my source list:
deb https://apt.readynas.com/packages/readynasos 6.10.8 updates apps main
deb http://mirrors.kernel.org/debian jessie main
deb http://security.debian.org/ jessie/updates main
deb http://archive.debian.org/debian etch main
deb http://mirrors.edge.kernel.org/debian/pool/main/b/build-essential/ stable main
deb https://deb.sipwise.com/debian/pool/main/d/dpkg/ stabel main
deb https://cloudfront.debian.net/debian-archive/debian/pool/main/d/dpkg/ jessie main
deb http://ftp.us.debian.org/debian stable main contrib
deb http://old.kali.org/kali/pool/main/m/make-dfsg/ jessie main- SandsharkSensei
Debian 8 has been archived, so in order to install anything, you have to make some changes. See How-I-got-apt-update-and-install-to-work-with-Debian-Jessie.
Hi, tanks for a quick answer. I follow instruction in the tread. Install build essentianl was without error, but after i want to update the softether vpn in step where i should use command "make" i have follow errors:
/usr/bin/ld: failed to merge target specific data of file lib/libncurses.a(lib_slkclear.o)
/usr/bin/ld: error: Source object lib/libncurses.a(lib_slktouch.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libncurses.a(lib_slktouch.o)
/usr/bin/ld: error: Source object lib/libz.a(compress.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libz.a(compress.o)
/usr/bin/ld: error: Source object lib/libz.a(uncompr.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libz.a(uncompr.o)
/usr/bin/ld: error: Source object lib/libz.a(deflate.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libz.a(deflate.o)
/usr/bin/ld: error: Source object lib/libz.a(inflate.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libz.a(inflate.o)
/usr/bin/ld: error: Source object lib/libz.a(inftrees.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libz.a(inftrees.o)
/usr/bin/ld: error: Source object lib/libz.a(trees.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libz.a(trees.o)
/usr/bin/ld: error: Source object lib/libz.a(zutil.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libz.a(zutil.o)
/usr/bin/ld: error: Source object lib/libz.a(adler32.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libz.a(adler32.o)
/usr/bin/ld: error: Source object lib/libz.a(crc32.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libz.a(crc32.o)
/usr/bin/ld: error: Source object lib/libz.a(inffast.o) has EABI version 0, but target vpnserver has EABI version 5
/usr/bin/ld: failed to merge target specific data of file lib/libz.a(inffast.o)
collect2: error: ld returned 1 exit status
Makefile:20: recipe for target 'main' failed
make[1]: *** [main] Error 1
make[1]: Leaving directory '/root/vpnserver'
