Forum Discussion
Monitor VLAN statistics using SNMP
Hello, I've some vlans configured. I'd like to monitor VLAN statistics using ifTable MIB table. But when I test using snmpwalk, I only see entries for the physical ports...
What standard MIBs do you had in mind?
Hi,
It's IF-MIB MIB
VLANs are not interfaces IMHO so unlikley IF-MIB. https://tools.ietf.org/html/rfc8892
One espresso later, I'd expect the port VLAN statistics to be here:
dot1qPortVlanStatisticsTable
.1.3.6.1.2.1.17.7.1.4.6You might give it a try, some parts of .1.3.6.1.2.1.17.7 seem to be around (on similar switches) when I have it right. This is part of the Q-BRIDGE-MIB which is not supported as per the https://www.netgear.com/support/product/GC752XP.aspx#download -> MIBs.
The documentation of dot1qPortVlanStatisticsTable looks promising.
Unfortunately it's not available on the switch when I tested with snmpwalk.
I've seen VLAN interface data were available on customer's lab using IF-MIB's ifTable on Cisco devices.
Huawei also supports it using IF-MIB based on the link I posted on original post.
So I thought Netgear would also supports it.
