Three GS308E, PFSense, cannot get VLAN working on third switch
I'm working on getting VLAN setup in my home network. All of the switches are GS308E and have the VLAN turned on for the type "Advanced 802.1Q VLAN". The "LAN" coming into Port 1 of Switch 1 is coming from the TPLink Switch that is connected to the PFSense box. Switch 1 with Port 2 connects to Switch 2 with Port 1. The same for Switch 2 Port 2 connects to Switch 3 with Port 1. Eventually Switch 3 with Port 2 will connect to a ReoLink PoE for my Cameras/Frigate setup. On Switch 1: Ports 6, 7, and 8 setup for VLAN 400. Ports 3 setup for VLAN 300. Ports 2 setup to go to Port 1 of Switch 2 Ports 1 setup to connect to the LAN On Switch 2: Port 1 is connected to Switch 1 Port 2 Port 2 is connected to Switch 3 Port 1 No VLAN has been setup at this point on this Switch On Switch 3: Port 1 is connected to Switch 2 Port 2 Port 8 is setup for VLAN 602 For all the Switches I have the VLAN 1 which is the default VLAN. For Switch 1, I'm able to connect my laptop with Ubuntu 24.04 and a Raspberry Pi 5 with Ubuntu 24.04 just fine to Port 6-8. I've tried to connect another computer (Ubuntu 24.04) to Switch 3 Port 8, but it fails to connect. I've taken my laptop and tried, but it also doesn't connect. Now when I connect to like Switch 3 port 6, it connects just fine. I started this post last night, but just finishing it up this morning. I'll dig back into the setup of things and see if I have done something incorrectly. Below is the setup of PFSense and an outline of how I have configured the Switches. If there is something else that I'm not included, please ask for it and I'll see if I can capture it, as I'll be messing around trying to get this to work. I've put in screen shots of the PFSense setup - put in bold of my comments so they stand out... PICS will be done during edits of this post - won't post to start... In Pfsense I can see my three switches (which have not been assigned a static IP at this point) In Pfsense, these are the VLAN setup. These are the Interface Assignments: Here is the Configuration of the SecurityCams2 (VLAN 602) The configuration of the DHCP Servier for VLAN 602 The last part, the Rules for the new VLAN. Switch Configurations =================== Ports-Connections and VLAN assignment ====== Switch 1 Port 1 - Connects to the LAN of the PFSense Box Port 2 - Connects to the Port 1 of Switch TWO Port 6 - VLAN 400 Port 7 - VLAN 400 Port 8 - VLAN 400 Switch 2 Port 1- Connects to LAN of the PFSense box going to Switch 1 port TWO Port 2- Connects to the Port 1 of Switch THREE Switch 3 Port 1 - Connects to LAN of the PFSense box going to Switch 2 port TWO Port 2 - Will connect to another switch, but have not connected at this point. Port8 - VLAN 602 VLANs Definition in Switch 1 --------------------------- VLAN=1 (Default) Port 1 - U Port 2 -U Port 3 - E Port 4- U Port 5- U Port 6- E Port 7- E Port 8- E VLAN=300 Port 1 - T Port 2 -T Port 3 - U Port 4- E Port 5- E Port 6- E Port 7- E Port 8- E VLAN=400 Port 1 - T Port 2 -T Port 3 - E Port 4- E Port 5- E Port 6- U Port 7- U Port 8- U VLANs Definition in Switch 2 --------------------------- VLAN=1 (Default) Port 1 - U Port 2 -U Port 3 - U Port 4- U Port 5- U Port 6- U Port 7- U Port 8- U VLANs Definition in Switch 3 --------------------------- VLAN=1 (Default) Port 1 - U Port 2 -U Port 3 - U Port 4- U Port 5- U Port 6- U Port 7- U Port 8- E VLAN=602 Port 1 - T Port 2 -E Port 3 - E Port 4- E Port 5- E Port 6- E Port 7- E Port 8- U PVID table ========= Switch 1 Port 1 - 1*, 300, 400 Port 2- 1*, 300, 400 Port 3- 300* Port 4- 1* Port 5- 1* Port 6- 400* Port 7 - 400* Port 8 - 400* Switch 2 -------- Port 1 - 1*, 602 Port 2- 1* Port 3- 1* Port 4- 1* Port 5- 1* Port 6- 1* Port 7 - 1* Port 8 - 602* Switch 3 Port 1 - 1*, 602 Port 2- 1* Port 3- 1* Port 4- 1* Port 5- 1* Port 6- 1* Port 7 - 1* Port 8 - 602*GS308Ev4, GS305E - Help with uplinks/downlinks
Could I please have some help or confirmation that I have these setup correctly? I'm weary that they are because I sometimes have trouble connecting to the admin interfaces on these switches. I've already locked myself out of about 5 of these (they become unreachable) and had to do factory resets and start over. Other times, I login and the admin pages don't fully load. Or sometimes they load with weird names and labels. Sometimes I logout and chrome says "no data from site". I'm concerned I'm losing some packets somewhere. But generally speaking, everything is working and the untagged (U) vlan access ports are divvying out the correct ip addresses and devices are communicating within themselves ok. I don't think I'm understanding how the uplinks/downlinks need to be tagged, or untagged. Here's the big picture. Looking at it on paper makes me feel like I'm way out of league. There's a lot of empty ports, I'm just starting. Here's the 4 port setup on the router Let me just start down the port 1 trunk (stuff on left of picture). Here's the setup of GS308Ev4-1 for VLAN1 Same router VLAN31 Same router pvid And then both GS305E-1 and -2 are setup the same which is: How am I doing?M4300 routing table Next Hop is Mgmt IP
Apologies for the dumb question: I have two M4300's stacked together with three VLANs configured. VLAN 10 has range 10.0.10.0/24, the gateway is (supposed to be) 10.0.10.1 and the management interface is at 10.0.10.252. However, the routing table for 10.0.10.0 shows the next hop as 10.0.10.252 which must have been set when I chose that IP for the management interface. I was expecting it to be the gateway not the management interface? In "IPv4 Management VLAN Configuration", The management VLAN is 10, Routing Mode is enabled, the IP Address/Subnet Mask are as above and the Gateway is 10.0.10.1. I can ping devices on VLAN10 including the management interface, but not the Gateway. Neither can I ping anything on the other VLANs. Is this normal or have I messed up my config somehow?VLAN
Hi an alle, ich habe einen GS752TXPv3 Switch und würde gerne ein VLAN 50 untagged erstellen 192.168.50.0/255.255.255.0 im VLAN1 - 192.168.1.0/255.255.255.0 läuft ein DHCP Server für VLAN1 u. VLAN50 Wie muss ich das VLAN50 am Switch konfigurieren das der DHCP relay zu diesem DHCP funktioniert ? Wie bekomme ich ein Routing von VLAN50 zu VLAN1 konfiguriert ?IP ACL Vlans MG5300
Hello, I would like to implement IPv4 ACL policies in a Vlan segmentated network. My core switch is an M5300-28G ProSafe 24-port Gigabit L2+ with 10 Gigabit Stacking, 10.0.0.44, B1.0.0.5. I have the following vlan on the MG5300: Vlan1 192.168.0.0/24 - Servers + Internet Gateway Vlan10 192.168.10.0/24 Vlan20 192.168.20.0/24 Vlan30 192.168.30.0/24 Vlan40 192.168.40.0/24 Vlan50 192.168.50.0/24 Vlan60 192.168.60.0/24 Vlan70 192.168.70.0/24 - Printers I need to implement: Vlan10 Acces to vlan1 (to permit access to Servers and Internet) Access to Vlan70 (to permit access to printers) No Access to Vlan20, vlan30, vlan40, vlan50, vlan60 Vlan20 Acces to vlan1 (to permit access to Servers and Internet) Access to Vlan70 (to permit access to printers) No Access to Vlan10, vlan30, vlan40, vlan50, vlan60 Vlan30 Acces to vlan1 (to permit access to Servers and Internet) Access to Vlan70 (to permit access to printers) No Access to Vlan20, vlan10, vlan40, vlan50, vlan60 Vlan40 Acces to vlan1 (to permit access to Servers and Internet) Access to Vlan70 (to permit access to printers) No Access to Vlan20, vlan30, vlan10, vlan50, vlan60 Vlan50 Acces to vlan1 (to permit access to Servers and Internet) Access to Vlan70 (to permit access to printers) No Access to Vlan20, vlan30, vlan40, vlan10, vlan60 Vlan60 Acces to vlan1 (to permit access to Servers and Internet) Access to Vlan70 (to permit access to printers) No Access to Vlan20, vlan30, vlan40, vlan50, vlan10 Which is the best way to implement this requirements ? Thanks so much !
GSM5212 voice VLAN killing LAN access for Yealink T42S phones
Objective - I'm trying to set up 3 T42S phones for a 3cx pbx installation on an OVH vps in STUN configuration behind a Netgear M4100-D12G switch using the Auto-Voice VLAN. The router is a Netgear R8000P configured with reserved IPs for each phone. The Problem - When any of the phones are reset for provisioning, network availability is permanently lost and can be recovered only by a hard factory reset. I isolated the problem by removing the ports used by the phones from the Auto-Voice vlan and network connectivity for the phones was restored after provisioning. I would really appreciate suggestions that would allow me to reinstate the Auto-Voice vlan feature.Need help creating vlan (802.1Q)
I have a GS724Tv2 switch which currently has all appliances connected on vlan1. The firewall appliance is connected to port1 and I have a wireless access point (AirPort Extreme) on port10. Its my understanding that the AP’s regular traffic is untagged and the guest traffic is tagged 1003. I am attempting to pass regular traffic from the AP on vlan1 untagged and guest traffic on a new vlan (vlan1003). I created the new vlan (vlan1003) and assigned port1 and port10 both tagged. Both these ports are also still assigned to vlan1 untagged. When I do this it appears that all traffic to the firewall is being blocked on vlan1 and vlan1003 is still not connecting. What did I miss?
