Switches indicate receiving signal, not detecting devices

Question

I have had a GS316EP for 4 years. It was used to power 2 PoE cameras and for my home office. About a month ago, it stopped working. When I plug the Cat 5e from the router into each port, they light up and I can check the status when I access the switch via the IP address. It shows 1 connection, despite there being at least 3 others attempting to pull/send data.

I purchased a GS3116PP Unmanaged Switch to replace it, thinking it was a dead switch, and it is doing the same thing. I have changed the cord from the router, trying a different cat 5e and a cat 6. No improvement.

Firmware has been updated on the managed device. The unmanaged device was left plugged in for over an hour, despite instructions claiming it should only take 2 minutes.

Any help would be appreciated.

StephenB · Answer

schumaku wrote:
The GS316EP is about a 200 W capable unit, 54V, delivering up to about 3.7 A, best guess, the GS316PP power supply is the very similar 200 W unit, 54V, 3.7A.

That's what I think too.&nbsp; But I am wondering if the original power brick is failing

StephenB · Answer

When you swapped the switches, did you also use the new power adapter with the new one?&nbsp; Or did you just plug in the old one?
&nbsp;
Does disconnecting the two PoE clients make any difference in the symptoms?

schumaku · Answer

Factory reset (default) the GS316EP, ensure the correct power supply is plugged.
&nbsp;
Are the connected devices in question PoE powered?
&nbsp;
Do non-PoE Ethernet devices connected show both Link and activity?
&nbsp;
The GS316EP is about a 200 W capable unit, 54V, delivering up to about 3.7 A, best guess, the GS316PP power supply is the very similar 200 W unit, 54V, 3.7A.
